The company mainly produces and sells: 10A, 16A, 32A marine copper connectors, nylon connectors, incandescent roof lights, navigation signals, floodlights, searchlights, fluorescent roof lights and fluorescent canopy lights and other series of products and various accessories.
| Name: |
Masthead light |
| Type: |
CXH3-3P |
| Visibility: |
2n.m |
| Level arc: |
225° |
| Lamp Holder: |
B15d |
| Bulb: |
12V25W40cd 24V25W60cd |
| Protection Class: |
IP56 |
| Cable Outside Diameter: |
Φ10-Φ12 |
| Color: |
Transparent |
| Weight: |
0.53kg |
Adopt standard:
1. Conform to《THE INTERNATIONAL REGULATIONS FOR PREVENTINGS COLLISION AT SEA, 1972》and《GRADE ENTRY NORMS FOR STEEL SHIPS》.
2. Conform to the international standard IEC60598-1-2008.
3. Conform to the standard of marine electric signal light's technical condition GB/T 3028-1995. Production authentication Approved by CCS (China lassification Society), and ZY of China Fishery Inspection.
The Masthead Light CXH3-3P is a great option for ships with a length of less than 12 meters. It's designed to be used as a lamp signal when night navigation.
The shell is made of high-strength engineering plastic PA+GF injection, and the lampshade adopts injection of PC. The lens hood adopts the high quality brass alloy. The signal lights have the whole seal structure, which makes them waterproof under bad environments. The signal lights choice the special signal bulb which conforms to ship norms, so you can easily replace it when opening up the top cover. These lights work normally under temperatures ranging from -30 degrees Celsius to 55 percent Celsius.
This product conforms to standards for preventing collisions at sea (1972), grade entry norms for steel ships (1975), international standard IEC60598-1-2008, marine electric signal light technical conditions GB/T 3028-1995 (CCS and ZY).Masthead light is the principal light signal of ships, it is the most important part of the ship's lights. The signal light can be seen in clear weather at a distance of 2 nautical miles.
The signal light mainly consists of outer tube, lamp holder and bulb. The outer tube is made of high strength engineering plastic PA+GF injection,the lampshade adopts injection of PC, the lens hood adopt the high quality brass alloy. The bulbs are sealed in the outer tube, which has a good waterproof performance. The signal lights have the whole seal structure and can work normally under -30°C ~55%C.
